INSTOCK READY TO GO
3 in 1 Hydraulic work station. Metal shear, Hole punch, and Metal bending.
Smart unit with swivel casters all around. Easy and precision metal work no many you are handy man or pro metal workshop. Great for circuit board manufacturer.
Metal Cut/Shear Guillotine Capacity: 20T
Maximum Plate width: 150mm
Maximum Cut thickness 8mm M.S. 5mm S.S.
Maximum Hole Punch Capactity :34T with the following dies(mm)
8.5; 9.5; 10.5; 12.5; 14.5; 16.5; 18.5; 20.5.
Additional dies available in other listing
Maximum Bending Capacity: 20T
Maximum Width: 150mm
Maximum Bending thickness: 10mm on M.S.
Built inSingle phase 240v 0.75kw hydraulic pump with resevior.
working modules are built on heavy duty work bench with stainless steel covers all round.
Foot actuation paddle and 5L of oil are supplied with machine
1 Year part replacement warranty.
Aus wide freight available with price guide as follow:
VIC: $60
NSW/SA Metro: $130
Brisbane: $180
Perth: $250
Not enough working capacity? we can upgrade the machine up to 3.5kw and 150t working capacity if needed. Please ask for details.
Payment to be made within 4 business days upon purchase. Item will be shipped out next business day. Approximate delivery time as follow via auswide road freight to metro areas:
VIC: 1-2 Days
NSW,SA: 2-3 Days
QLD: 3-5 Days
Perth, NT, TAS: 5-7 Days
Freight time may take longer for regional areas. Tracking number will be provided once booking is made.
Located Melbourne Northern Suburb, pickup available upon purchase.
For pick up: CRANK MOTORSPORT
Croydon South VIC
*Thank you and happy shopping!*
